EVO80 - TKL Fully-Built ISO Mechanical Keyboard
EVO80 - TKL Fully-Built ISO Mechanical Keyboard
Available in stock
The EVO80 is the perfect blend of comfort, design, and performance. Made entirely of aluminum, it offers a smooth, responsive, and ultra-pleasant keystroke thanks to its Butterfly Leaf Spring system and screwless mounting. Connect it however you like (USB-C, Bluetooth, or 2.4 GHz), swap out your switches in a snap, and enjoy a muted sound with every keystroke.
Designed for creatives, enthusiasts and people who want to evolve their setup!
The nice touch: Compared to other Custom Keyboard, the EVO80 offers a French, Spanish or German layout to adapt to everyone!
⭐ EVO80 Specifications:
- Mechanical Keyboard TKL
-
Layout ISO (French, Spanish or Deutch)
- Butterfly Leaf Spring Mounted for a soft typing feeling
- Ball-catch Disassembly Mechanism and Magnetic Connectors
- CNC 6063 Aluminum Case
- PP Plate
- Oat Linear Switches
-
Tri-mode ANSI Hotswap PCB
- Per-key RGB
- Polling rate: Wired & 2.4GHz 1000Hz, Bluetooth 125Hz
- VIA Compatible
- Support USB-C, Bluetooth, and 2.4GHz dongle connection
- Battery: Two 4000mAh Capacity
- Per-key RGB
- Keycaps Dye-Sub PBT
- Dimensions: 357 x 136.4mm
- Weight: 1870g
- Compatibility: Windows, Mac, Linux, iOS, Android
Includes:
Includes:
EVO80 Keyboard:
- 1 Keyboard Case
- 1 PCB, Daughterboard, Internal Battery
- 1 PP Plate
- 1 Set of Switches
- 1 Keycap Set
- 1 Acoustic Package (2 Poron Case Foam, 1 PET Sheet, 1 IXPE Sheet, 1 Plate Foam)
- 1 Set Stabilizers
- 1 Set Butterfly Leaf-springs and Gaskets
- 1 Set Silicone Corner Protectors and Rubber Feet
Accessories:
- Spare switches, screws, leaf-spring dampeners, gaskets, case silicone dampeners
- USB-C Cable
- 2.4GHz Dongle
- Keycap & Switch Puller
- Mac Add-on Kit
- 1 Carrying Case
Your payment information is processed securely. We do not store credit card details and we not have access to your credit card information.
EVO80 TKL
Introducing the EVO80 TKL. Featuring custom keyboard standards, this plug-and-use Mechanical keyboard delivers a premium feeling to evolve your setup!
Design
On the side, they crafted a curvilinear contour between the top and bottom cases to ensure a smooth transition. Coupled with a uniquely colored battery compartment for each case color, your Evo80 looks dynamic and delicate from every angle.
Butterfly Leaf Spring Structure
The leaf spring mounting system is one of the proudest structural innovations of Owlab. Compared to the commonly used gasket mount, it provides softer support and a bouncier typing feedback.
However, due to cost constraints, the leaf spring structure is typically only utilized on high-end mechanical keyboards.
Effortless Disassembly + Magnetic Connectors
They’ve retained the highly praised ball-catch mechanism and magnetic connectors from the Neo Studio. You can easily open the case with a press and lift, no tools required.
Although the EVO80 is ready to use right out of the box, this easy disassembly structure allows you to change keycaps without worring about damaging the top case.
Acoustic Performance
While some may claim that all keyboards sound similar with foam, we hold a different view.
The acoustic package for the Evo80 is meticulously custom-designed to align with its specific case structure and internal components. Through enhancements in materials and cutout design, it ensures that the Evo80 brings forth the precise sound profile we have envisioned for you.
Keycaps
Dye-Sub PBT keycaps have been chose to improve the characteristics of the switches and release the powerful sound of the internals, and also developed new molds to address previous internal housing issues, giving the Evo80 a more excellent sound performance and typing experience.
The keycaps feature the Cherry profile, ensuring a familiar and comfortable typing experience right out of the box.
PCB
Tri-Mode Hotswap PCB
- ANSI or ISO Layout
- Per-key RGB
- NKRO
- Polling rate: Wired & 2.4g 1000Hz, Bluetooth 125Hz
- VIA compatible
- Support USB-C, Bluetooth, and 2.4GHz connection
- Equipped with two 4000mAh batteries with NTC fast-charging core chips
